PARTS LIST P SERIES
Page 84 of 100
CABINET AND VEND MECHANISM (Section 1)
ITEM
PART DESCRIPTION DN504P DN720P
Kit, Door Hinge Assembly
Chameleon 642,053,40x.x4 609,051,40x.x3
1
All LMV 642,053,40x.x4 SAME
Cover, Hinge Pocket
2
All 631,051,07x.x3 SAME
Block, Foam
3
All 903,300,77x.x1 SAME
Top Hinge (Main Door)
Chameleon 631,051,09x.x3 SAME
4
All LMV 642,050,35x.x3 631,051,09x.x3
Hinge, Spacer
5
All 169,000,15x.x3 SAME
Bearing, Hinge – Pin less
6
All 805,300,67x.x1 SAME
Hinge, Bottom Assembly (Main Door)
Chameleon 631,152,40x.x3 SAME
7
All LMV 642,051,80x.x3 SAME
Sleeve, bottom hinge
8
All 900,502,64x.x1 SAME
Washer,R, Door Hinge
9
All 800,701,73x.x1 SAME
Stack Supports (4)
10
All 651,070,02x.x3 SAME
Ingress Guard Assembly
11
All 640,071,40x.x3 639,076,00x.x3
Mullion
12
All 801,819,57x.x1 801,819,58x.x1
Mullion Cap
13
All 801,818,92x.x1 801,818,93x.x1
Breaker Strip - Top
14
All 493,020,06x.x3 491,020,17x.x3
Breaker Strip - Left
15
All 639,020,05x.x3 SAME
Breaker Strip - Right
16
All 639,020,09x.x3 SAME
Roller, Main Door
17
All 901,806,20x.x1 SAME
Pin, Door Roller 5/32x2-3/8
18
All 800,503,78x.x1 SAME
Retainer, Door Roller Pin
19
All 900,900,90x.x1 SAME
Lock Housing Assembly
20
All 639,072,50x.x3 SAME
Cabinet Assembly
Chameleon 652,061,20x.x3 651,061,00x.x3
21
All LMV 652,061,10x.x3 651,061,10x.x3
Plate, Protective Left Side (Specify Color)
Black 649,000,01x.x3 SAME
22
Red 651,050,46x.x3 SAME
Part number and description subject to change with out notice. NA = Not applicable TBD = To be determined RB = Replaced by
To Next Page
