PARTS LIST P SERIES
Page 87 of 100
CABINET AND VEND MECHANISM (Section 2)
ITEM PART DESCRIPTION DN504P DN720P
Stack Assembly
All Except Italy 652,070,20x.x3 651,070,20x.x3
1
Italy 652,070,50x.x3 NA
2
Assembly Rear Spacer Narrow 639,070,27x.x3 SAME
3
Bracket, Rear Spacer Narrow (2) 801,819,56x.x1 SAME
4
Guide, Channel Rear Spacer (2) 801,819,59x.x1 SAME
5
Latch, Rear Spacer (2) 801,819,61x.x1 SAME
6
Guide Arm Assembly (2) 805,202,57x.x1 SAME
7
Vend Motor - Narrow Column 804,501,63x.x1 SAME
8
Rotor 801,307,87x.x1 SAME
9
Load Bar - Steel 801,306,59x.x1 SAME
10
Push Arm 801,819,55x.x1 SAME
11
Push Arm Spring 801,701,51x.x1 SAME
12
Nyliner .312 801,819,53x.x1 SAME
13
Nyliner .750 801,819,52x.x1 SAME
14
Bushing, Load Bar .312 801,819,54x.x1 SAME
15
Screw, Phil Pan 8-32x1 (3) 800,304,92x.x1 SAME
16
Vend Motor Cover 640,071,70x.x3 639,072,70x.x3
Front Gate Extension
17
All 639,070,14x.x3 SAME
Air Baffle - KYDEX
18
All Wide NA 639,070,68x.x3
Harness,R,Stack
19
All 000410 000596
CABINET AND VEND MECHANISM ( Section 2 ) - MISCELLANEOUS
A1 Rivet,R,1/8 Steel Zinc Plate (53) 801,100,81x.x1 SAME
A2 Rivet,R,3/16 Steel Zinc Plate (44) 801,100,79x.x1 SAME
A3 Screw,R,1/4-20x5/8 Hex Type F SEMS (4) 800,304,36x.x1 SAME
A4 Screw,R,8-32x3/8 Phillip Pan Type 1 (2) 800,304,22x.x1 SAME
A5 Label,R,Upper Fill Narrow Column, Upper (2) 803,876,01x.x1 SAME
A6 Label,R,Upper Fill Narrow Column, Lower (2) 803,876,03x.x1 SAME
A7 Tie,R,5.5" Hand 901,901,06x.x1 SAME
A8 Label,R,Vend Motor 803,871,19x.x1 SAME
A9 Kit, ID Number Labels 640,070,55x.x4 639,070,76x.x4
A10 Tie,R, 5.5" Hand 901,901,06x.x1 SAME
Part number and description subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
