Dixie DN720P - PARTS LIST - EVAPORATOR FAN ASSEMBLY DETAILS; Evaporator Fan Components and Hardware

PARTS LIST P SERIES
Page 91 of 100
EVAPORATOR FAN ASSEMBLY
ITEM
PART DESCRIPTION DN504P DN720P
Evaporator Fan Shroud Assembly
All except Energy Star 640,040,10x.x3 639,040,20x.x3
Energy Star 640,041,30x.x3 639,041,50x.x3
Service Kits 646,070,00x.x3 646,040,40x.x3
220v Export 640,040,80x.x3 639,040,70x.x3
1
Italy 640,040,80x.x3 NA
Evaporator Fan Shroud
All except Energy Star 640,040,20x.x3 639,040,30x.x3
Energy Star 640,040,13x.x3 639,040,06x.x3
220v Export 640,040,20x.x3 639,040,30x.x3
2
Italy 640,040,20x.x3 NA
Harness, Evaporator Fan
All except Energy Star 804,921,73x.x1 804,921,73x.x1
Energy Star 804,926,33x.x1 SAME
220v Export 804,921,73x.x1 804,921,73x.x1
3
Italy 804,921,73x.x1 NA
Evaporator Fan Motor Assy.
All except Energy Star 640,040,30x.x3 SAME
Energy Star 804,501,54x.x1 SAME
220v Export 639,040,60x.x3 SAME
4
Italy 639,040,60x.x3 NA
Blade,R, Fan 6" 4-Blade Plastic
5
Italy 801,818,88x.x1 NA
Motor,R, Evaporator Fan 220/50,60
6
Italy 804,501,72x.x1 NA
Bracket, Evaporator Fan
7
Italy 640,040,06x.x3 NA
8
Bracket, Evaporator Fan Panel Left Hand 640,040,08x.x3 SAME
9
Bracket, Evaporator Fan Panel Right Hand 640,040,07x.x3 SAME
10
Cover, Evaporator Top 640,040,09x.x3 SAME
11
Rear Air Stop Assembly 640,040,60x.x3 NA
12
Choke - Energy Star 804,926,92x.x1 SAME
13
Temperature Sensor 804,925,43x.x1 SAME
14
Bracket, Temp Sensor 639,040,04x.x3 SAME
EVAPORATOR FAN ASSEMBLY - MISCELLANEOUS
A1
Screw, Phil Pan 8 - 18 x 1/2" (4) 800,304,18x.x1 SAME
A2
Screw,R, 8-32x3/8 Phillip Pan Type 1 800,304,22x.x1 SAME
A3
Screw,R,8-18x1/2 Phillip SD SEMS (9) 800,304,23x.x1 SAME
A4
Screw, 10-32x1 1/4" Phil Pan Type F B 800,304,28x.x1 SAME
A5
Screw,R,8-18x1/2 Phillip Pan AB Machine (6) 800,304,31x.x1 SAME
A6
Screw, 1/4-20x5/8 Hex Type F 800,304,36x.x1 SAME
A7
Hex Nut, 11/32" (6) 800,801,54x.x1 SAME
A8
Rivet, 1/8" Steel 801,100,81x.x1 SAME
A9
Clamp, Cable, 3/8" Nylon 900,902,43x.x1 SAME
A10
Tie,R, 5.5 “ Hand 901,901,06x.x1 SAME
A11
Bushing, ¾” split Heyco 901,902,17x.x1 SAME
A12
Tie, 5.5 “ Hand W223 SAME
Part number and description subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
