2019 DJI All Rights Reserved.
43
With a strong GNSS signal
Flight Limits
Max Height Flight altitude must be below the preset height.
Max Radius Flight distance must be within the max radius.
With a weak GNSS signal
Flight Limits
Max Height Flight altitude must be below the preset height.
Max Radius No limit.
If the aircraft flies into a Restricted Zone, it can still be controlled, but the aircraft can only fly in
a backward direction.
If the aircraft loses GNSS signal and flies out of the max radius but regains GNSS signal later,
it will fly back within range automatically.
GEO Zones
GEO Zones are divided into different categories. All GEO Zones are listed on the DJI official website at
http://www.dji.com/flysafe.
GEO Zones are explained below (GNSS required):
Depending on the local regulation, a certain radius around a marker forms a Restricted Zone, inside of
which takeoff and flight are prohibited.
Restricted Zone Free Zone
R
