AGRAS T16
User Manual
Flight Test
1. Place the aircraft on open, flat ground with the aircraft status indicators facing toward you.
2. Pour liquid into the spray tank, and tighten the cover. Make sure that the four lines on the cover are
aligned to the horizontal or vertical direction.
3. Power on the remote controller, make sure that DJI MG2 is open, and then power on the aircraft.
4. Make sure that the aircraft is connected to the remote controller.
5. If using RTK for positioning, make sure that the RTK function is enabled and RTK service type is
correctly set (D-RTK 2 Mobile Station or Network RTK service). Go to Operation View in DJI MG2, tap
and select RTK to view and set.
Make sure to disable the RTK function if it is not in use. Otherwise, the aircraft is not be able to take
off when there is no differential data.
6. Wait for satellites to be searched, make sure that there is a strong GNSS signal, and make sure the
aircraft heading measurement using the dual antennas is ready. Perform the CSC to start the motors.
(If the dual antennas are not ready after waiting for an extended period, move the aircraft to an open
area with a strong GNSS signal.)
7. Push the throttle stick up to take off.
8. Select the desired operation or flight mode and start operation.
9. Exit the operation to manually control the aircraft for landing. Hover over a level surface and gently
pull down on the throttle stick to slowly descend.
10. After landing, push the throttle down and hold. The motors stop after three seconds.
11. Power off the aircraft, and then power off the remote controller.
When the aircraft status indicators rapidly blink yellow during flight, the aircraft has entered
Failsafe mode.
The low battery level warning is triggered when the aircraft status indicators slowly blink red.
Fly the aircraft to a safe area and land as soon as possible, stop the motors, and replace the
battery. The critical low battery level warning is triggered when the aircraft status indicators
rapidly blink red. The aircraft will begin to automatically descend and land.
