DJI Mini 4 Pro
User Manual
10
  
©
2023 DJI All Rights Reserved.
Using for the First Time
Preparing the Aircraft
All aircraft arms are folded before the aircraft is packaged. Follow the steps below to unfold the
aircraft.
1. All Intelligent Flight Batteries are in hibernation mode before shipment to ensure safety.
Charge to activate the batteries for the rst time. Connect the USB charger to the USB-C port
on the aircraft to charge. The battery is activated when it begins charging.
PD
30W
2. Remove the propeller holder.
https://s.dji.com/guide66
Click the link below or scan the QR code to watch
the tutorial video.
The maximum takeoff weight will be more than 249 g if the aircraft is used with the
Intelligent Flight Battery Plus. Make sure to observe local laws and regulations about the
takeo weight.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji MINI 4 PRO and is the answer not in the manual?

dji MINI 4 PRO Specifications

General IconGeneral
Weight249 g
Max Flight Time34 minutes
Camera Sensor1/1.3-inch CMOS
Max Descent Speed5 m/s
Max Horizontal Speed16 m/s
Max Wind Speed Resistance10.7 m/s (Level 5)
Effective Pixels48 MP
ISO Range Video100-6400
ISO Range Photo100-6400
Max Video Bitrate150 Mbps
Video Transmission SystemO4
Live View Quality1080p/60fps
Max Speed16 m/s
Charging Time64 minutes
GNSSGPS+Galileo+BeiDou
Max Video Resolution4K
Max Transmission Range20 km
Obstacle SensingOmnidirectional
Dimensions (Folded)148×94×64 mm
LensFOV 82.1°, f/1.7
Digital Zoom4x
Gimbal3-axis (tilt, roll, pan)
Operating Frequency2.4000-2.4835 GHz, 5.725-5.850 GHz
Operating Temperature-10° to 40° C
