dji MINI 4 PRO User Manual

DJI Mini 4 Pro
User Manual
12
©
2023 DJI All Rights Reserved.
Preparing the Remote Controller
DJI RC 2
1. Remove the control sticks from the storage slots and mount them on the remote controller.
1
2
2. Unfold the antennas.
3. The remote controller needs to be activated before rst use and an internet connection is
required for activation. Press, and then press and hold the power button to power on the
remote controller. Follow the on-screen prompts to activate the remote controller.
DJI RC-N2
1. Remove the control sticks from the storage slots and mount them on the remote controller.
2. Pull out the mobile device holder. Choose the appropriate remote controller cable based
on the port type of your mobile device (a Lightning connector cable and a USB-C cable are
included in the packaging). Place your mobile device in the holder, then connect the end of
the cable without the remote controller logo to your mobile device. Make sure your mobile
device is securely in place.

dji MINI 4 PRO Specifications

General

Weight	249 g
Max Flight Time	34 minutes
Camera Sensor	1/1.3-inch CMOS
Max Descent Speed	5 m/s
Max Horizontal Speed	16 m/s
Max Wind Speed Resistance	10.7 m/s (Level 5)
Effective Pixels	48 MP
ISO Range Video	100-6400
ISO Range Photo	100-6400
Max Video Bitrate	150 Mbps
Video Transmission System	O4
Live View Quality	1080p/60fps
Max Speed	16 m/s
Charging Time	64 minutes
GNSS	GPS+Galileo+BeiDou
Max Video Resolution	4K
Max Transmission Range	20 km
Obstacle Sensing	Omnidirectional
Dimensions (Folded)	148×94×64 mm
Lens	FOV 82.1°, f/1.7
Digital Zoom	4x
Gimbal	3-axis (tilt, roll, pan)
Operating Frequency	2.4000-2.4835 GHz, 5.725-5.850 GHz
Operating Temperature	-10° to 40° C
