dji RONIN 2 User Manual

Ronin 2 User Manual
8
©
2017 DJI OSMO All Rights Reserved.
Camera Size Requirements
The maximum depth from the center of gravity on the camera base plate is 250 mm.
The maximum height, measured from the top of the camera base plate, is 170 mm. The
maximum width is 190 mm.
Make sure the camera is powered off during installation.
It is recommended to use soft connection cables to avoid obstructing camera
movement.
Mounting a Camera
1. Unlock the levers and remove the upper crossbar .
2
1
250mm
190mm
170mm

dji RONIN 2 Specifications

General

Gimbal Accuracy	±0.02°
Gimbal Type	3-axis
Pan Range	360°
Operating Frequency	2.4 GHz
Battery Voltage	22.2 V
Compatibility	Various cameras and accessories
Payload Capacity	13.6 kg
Battery Life	2.5 hours
Operating Temperature	-20°C to 50°C
Tilt Range	-135° to 135°
Roll Range	360°
Connectors	USB
Charging Time	Approx. 90 minutes (using DJI Charger)
