Ronin 2
User Manual
16
©
2017 DJI OSMO All Rights Reserved.
Assistant 2 app.
3. Balancing Function: Automatically balances the voltage of each battery cell when
charging.
4. Overcharge Protection: Charging stops automatically when the battery is fully
charged.
5. Temperature Protection: The battery will only charge when the temperature is between
5-45° C (41-113° F).
6. Overcurrent Protection: Battery stops charging when high amperage (> 10 A) is
detected.
7. Over-Discharge Protection: To prevent serious damage to the battery, current output
will be cut off when the battery cell is discharged to 2.8 V and not in use. To extend
operating times, overcharging protection is disabled as batteries discharge during
usage. In this instance, a battery voltage below 2 V may cause a safety hazard such
as a re when charged. To prevent this, the battery will not be able to charge if the
voltage of a single battery cell is below 2 V. Avoid using any batteries matching this
description. Always be alert to avoid over-discharging to prevent permanent battery
damage.
8. Short Circuit Protection: Automatically cuts the power supply when a short circuit is
detected.
9. Battery Cell Damage Protection: DJI Assistant 2 displays a warning message when
detecting a damaged battery cell.
10. Sleep Mode: Sleep mode is entered to save power when the battery is not in use.
11. Communication: Battery voltage, capacity, current, and other relevant information is
provided to the gimbal.
12. Pairing Batteries: Powered by two batteries (with battery cells connected in parallel),
the Ronin 2 requires the two batteries to have similar properties, e.g., internal
resistance. Pairing batteries in the beginning is recommended. Pairing can be done
using DJI Assistant 2, which will also prompt when batteries that are not paired are in
use. The Intelligent Battery Charging Hub will charge paired batteries simultaneously.
13. Heating: Batteries can work even in cold weather. Refer to "Using the Battery" section
for details.
Read the user manual, disclaimer, and battery safety guidelines before use. Users
take full responsibility for all operations and usage.
Charging the Intelligent Battery
The Ronin 2 Quad Charging Hub is designed for use with the Ronin 2 Battery Charger. It
charges up to four Intelligent Batteries simultaneously. The battery pair with more stored
power will be charged rst. If batteries are not paired, the Charging Hub will intelligently
charge batteries in sequence according to battery power levels from high to low. Pairing
can be carried out using DJI Assistant 2.
