dji Ronin-MX User Manual

Ronin-MX User Manual
©
2016 DJI All Rights Reserved.
27
3. If using Launchpad to launch DJI Assistant for the first time, Launchpad will block
access because DJI Assistant has not been reviewed by Apple.
4. Locate the Gimbal app using Finder, then press “Control” and click the icon (or right-
click the icon if using a mouse). Choose Open from the shortcut menu, then click
Open in the dialog box to launch the program.
5. After successfully launching the program for the rst time, double-click the Gimbal app
icon, as usual, to launch the program using Finder or Launchpad.
TIPS
The DMG installer supports Mac OS X 10.9 or above.
DJI Assistant on Mac OS X and Windows are the same. DJI Assistant pages
shown in this manual are from the Windows version.
Settings
Adjust the parameters for the following functions before using the Ronin-MX: Camera
Type, Briefcase Mode, SmoothTrack, and Maximum Speed Adjustment.
The definitions and functions of every button in the DJI Assistant app and the DJI
Assistant software for PC/MAC are the same. Refer to the section describing the DJI
Assistant app for more details.

dji Ronin-MX Specifications

General

Bluetooth	Yes
Type	Hand camera stabilizer
Material	Magnesium
Motorized	-
Pan range	0 - 360 °
Product color	Black
Number of axis	3
Tilt angle range	-150 - 270 °
Angle of rotation	360 °
Compatible products	ARRI ALEXA MINI, RED DRAGON, CANON 5D, Blackmagic Design Production Camera
Maximum weight capacity	4.5 kg

Weight and Dimensions

Depth	370 mm
Width	560 mm
Height	440 mm
Weight	2770 g
