DLab D3024 - 1 Specifications; 2 Declaration of Conformity

USER MANUAL
4
1. Specifications
Maximum speed
15000rpm(200-15000rpm), increment: 10rpm
Maximum RCF
21380 × g, increment: 10 × g
Maximum capacity
2ml × 24, 0.5ml × 36, 4-PCR8 serial tubes
Temperature range
-20℃-40℃(D3024R)
Timer
30seconds -99minutes-HOLD, continuous operation
Driving Motor
Brushless DC motor
Safety devices
Dual door interlock、Over-speed detector、Over-temperature detector、
Automatic internal diagnosis
Power requirements
D3024:
Single-phase, 220V-240V, 50Hz/60Hz, 5A.
110V-120V, 50Hz/60Hz, 5A
D3024R:
Single-phase, 220V-240V, 50Hz/60Hz, 10A.
110V-120V, 50Hz/60Hz, 10A
Dimensions（mm）
D3024:（L）280 × （W）364 × （H）266
D3024R:（L）338 × （W）580 × （H）324
Weight
D3024: 12kg
D3024R: 30kg
Additional features
Speed/RCF switch、Pulse operation、Processing display、Voice reminder
2. Declaration of Conformity
Construction in accordance with the following safety standards:
EN 61010-1
EN 61010-2-10
Construction in accordance with the following EMC standards:
EN 61326-1/ FCC Part 15 Subpart B/ IECS 001
Associated EU guidelines:
EMC-guidelines: 2004/108/EC
Instrument guidelines: 2006/95/EC
This ISM device complies with Canadian ICES-001.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
