10.3 Replacement of fuses
⚫ （1）There are two fuses of D3024, 250V, 5A time-delay type, size: Ф5×20. There are two fuses of
D3024R, 250V, 10A time-delay type, size: Ф5×20.
⚫ （2）The fuse holder is located in the power inlet. Pull out the fuse holder from power inlet and replace
the fuses if necessary.
11. Instructions of rotor and tube
CAUTION：
⚫ Read the instructions thoroughly, correct use rotor.
⚫ Do not exceed the allowable maximum speed of rotor、tube and adapters etc., be care that the allowable
maximum speed of some adapters are lower than the rotor
‟
s maximum speed.
11.1 The rotor instructions
11.1.1 Rotor structure
Knob Locking nut Cover
Seal ring Shaft hole
Figure 11-1 The rotor structure
11.1.2 Available rotors and adapters
All rotors are used for bio-safe when the rotor lid was tightened with the rotor, centrifuge tubes will be
