Digital Monitoring Products, Inc. | 734N Installation and Programming Guide 17
PROGRAM THE 734N
When you program a 734N, you must use a keypad connected to the 734N programming header and
set to address 1. For 12V applications, connect the keypad to the module using a Model 330 4-wire
harness. For 24V applications, connect the keypad to the module using a Model 330-24 4-wire
programming harness with in-line resistor.
Warning: Do not connect a keypad using a standard Model 330 harness if using a 24V power
supply! Damage to the keypad could occur.
You can also program the 734N from an XR150/XR550 Series panel. Initial programming of device
and communication must be performed with a keypad. Afterwards, device programming and 734N
options may be programmed from the panel’s programming interface. The panel’s programming
overrides any programming performed from a keypad connected to the 734N.
While the 734N is in programming mode, it will not be able to communicate with the panel.
RESET HEADER
To reset the module when first installing the system, short the two pins on the reset header before
applying power to the module.
To reset the module while the system is operational, short the two pins on the reset header for one or
two seconds without powering down the system.
