INSTALL THE 734N
The 734N comes in a high-impact plastic housing that you can mount directly to a wall,
backboard, or other flat surface.
DMP recommends mounting the 734N near the protected door. For easy installation, the back and
ends of the 734N housing have wire entrances. The back also contains multiple mounting holes
that allow you to mount the 734N on a single-gang switch box. See Figure2 for mounting hole
locations on the housing base.
1
MOUNT THE DEVICE
Mounting Hole
Figure 2: Mounting Hole Locations
