Digital Monitoring Products, Inc. | 7800 Series Installation and Programming Guide 17
PROGRAM THE KEYPAD
Refer to the appropriate panel programming guide as needed. Keep in mind that operation
for some programming options is restricted to the appropriate model. To access the
Keypad Options menu, press Options in the carousel menu. Press the Installer Options
wrench icon, enter 3577 (INST), then press CMD.
KEYPAD OPTIONS
To program keypad options, press the select area under KPD
OPT. When finished programming, press STOP to save all
programming.
Current Keypad Address
Set the current keypad address from 1 to 8 for XT30/XT50 or
XR150 Series panels, or 1 to 16 for XR550 Series panels. The
default address is set at 01. To change the current address,
press any select area to clear the keypad display, enter the
new address, and press CMD. It’s not necessary to enter a
leading zero for addresses 1 to 9.
KPD KPD
OPT DIAG STOP
CURRENT KEYPAD
ADDRESS: 01
