34 7800 Series Installation and Programming Guide | Digital Monitoring Products, Inc.
Update the Keypad
Restart Keypad on keypads running Version 107 or
higher allows the technician to restart the keypad to
initiate a firmware update from a microSD card. This
process takes approximately 5 minutes to complete.
Update Keypad Firmware Using Restart
1. Navigate to DMP.com/Dealer_Direct and
select Software Downloads from the
navigation menu.
2. Select a Software Update.
3. Click Download and enter Your Name, Your
Company, and Email information.
4. After the .zip download is complete, unzip the files and save them all to the root
directory of a FAT32 format microSD card.
5. Insert the microSD card into the microSD card slot on the right side of the keypad.
Refer to Figure 13.
6. Press Options in the carousel menu and press the Installer Options or wrench icon.
7. Enter 3577 (INST) at the keypad and select KPD OPT.
8. Press CMD until Restart Keypad displays.
9. Press Restart. Do not remove the microSD card or disrupt power.
10. When the keypad is finished restarting and returns to the home screen, remove the
microSD card.
Figure 17: Restart Keypad
