Digital Monitoring Products, Inc. | 7800 Series Installation and Programming Guide 29
Press the first select key or area to choose OFF (Relay
Always O). The relay does not turn on when any Wiegand
string is received. OFF does not aect any REX operation. If
communication is lost during a door strike, the relay remains
on for the door strike duration but turns o at the end of the
door strike timer.
Press the second select key or area to choose SITE (Accept
Site Code). Door access is granted when the site code string
received matches any programmed site code. Refer to Require
Site Code for more information.
Press the third select key or area to choose ANY (Any
Wiegand Read). Access is granted when any Wiegand string is
received.
Press the fourth select key or area to choose ON (Relay
Always On). The relay is always on.
Press CMD to display additional actions. Press the first
select key or area to choose LAST (Keep Last State). The
relay remains in the same state and does not change when
communication is lost.
OFF SITE ANY ON
OFF SITE ANY ON
OFF SITE ANY ON
OFF SITE ANY ON
LAST
