6.8 Power Requirements

During AC power failure, the XR150/XR550 Series panel and all connected auxiliary devices draw their power

from the battery. All devices must be taken into consideration when calculating the battery standby capacity. The

following table lists the XR150/XR550 Series panel power requirements. You must add the additional current draw of

keypads, zone expansion modules, smoke detector output, and any other auxiliary devices used in the system for the

total current required. The total is then multiplied by the number of standby hours required to calculate the total

ampere-hours required.

Standby Battery Power Calculations Standby Current Alarm Current

XR150/XR550 Series Control Panel

Relay Outputs 1-2 (ON)

Switch Grounds 3-6 (ON)

Active Zones 1-8

Active Zones 9-10

2-Wire Smoke Detectors

Panel Bell Output

Qty 1

Qty _______

x 174mA

30mA

5mA

1.6mA

4mA

0.1mA

174 mA

______

Qty 1

Qty _______

x 217mA

30mA

5mA

2mA*

30mA

0.1mA

1500mA

217 mA

______

______mA

893A Dual Phone Line Module Qty _______ x 12mA ______ Qty _______ x 50mA ______

263C CDMA Cellular Communicator Card

Qty _______ x 13mA ______ Qty _______ x 13mA ______

263H HSPA+ Cellular Communicator Qty _______ x 24mA ______ Qty _______ x 28mA ______

277 Buzzer Module Qty _______ x 5mA ______ Qty _______ x 5mA ______

1100X Wireless Receiver Qty _______ x 46mA ______ Qty _______ x 46mA ______

1100XH Wireless High Power Receiver Qty _______ x 160mA ______ Qty _______ x 160mA ______

860 Relay Output Module (one relay active)

All four relays active

Qty _______ x 34mA

138mA

______

Qty _______ x 34mA

138mA

______

865 Style Y or Z Notication Module Qty _______ x 26mA ______ Qty _______ x 85mA ______

866 Style W Notication Module Qty _______ x 45mA ______ Qty _______ x 76mA ______

867 LX-Bus Style W Notication Module Qty _______ x 30mA ______ Qty _______ x 86mA ______

869 Dual Style D Initiating Module Qty _______ x 25mA ______ Qty _______ x 75mA ______

630F Remote Fire Command Center Qty _______ x 63mA ______ Qty _______ x 92mA ______

7060/7160 Thinline/7060A Aqualite Keypad Qty _______ x 72mA ______ Qty _______ x 80mA ______

7063/7163 Thinline/7063A Aqualite Keypad Qty _______ x 85mA ______ Qty _______ x 100mA ______

7070/7170 Thinline/7070A Aqualite Keypad

Active Zones (EOL Installed)

Qty _______ x 72mA

1.6mA

______

Qty _______

87mA

2mA*

______

7073/7173 Thinline/7073A Aqualite Keypad

Active Zones (EOL Installed)

Qty _______ x 85mA

1.6mA

______

Qty _______

100mA*

2mA

______

7760 Clear Touch Keypad Qty _______ x 65mA ______ Qty _______ x 115mA ______

7872 Graphic Touchscreen Keypad

Active Zones (EOL Installed)

Qty _______ x 130mA

1.6mA

______

Qty _______

188mA

2mA*

______

7873 Graphic Touchscreen Keypad

Active Zones (EOL Installed)

Qty _______ x 130mA

1.6mA

______

Qty _______

188mA

2mA*

______

734 Wiegand Interface Module

Active Zones (EOL Installed)

Annunciator (ON)

Qty _______

15mA

1.6mA

______

Qty _______

15mA

2mA*

20mA

______

734N Wiegand Interface Module

Active Zones (EOL Installed)

Annunciator (ON)

Wiegand Reader

Qty _______

146mA

1.6mA

200mA

______

Qty _______

148mA

2mA*

20mA

200mA

______

734N-WiFi Wiegand Interface Module

Active Zones (EOL Installed)

Annunciator (ON)

Wiegand Reader

Qty _______

146mA

1.6mA

200mA

______

Qty _______

148mA

2mA*

20mA

200mA

______

Copy Sub-Totals to next page Sub-Total Standby ______mA Sub-Total Alarm ______mA

*Based on 10% of active zones in alarm.
