XR150/XR550 Series Installation Guide Digital Monitoring Products
5
SYSTEM COMPONENTS
3.3 Accessory Devices
Cellular Communicator Cards
263C CDMA Cellular Communicator Allows you to connect the XR150/XR550 Series to any compatible CDMA/SMS network.
263H HSPA+ Cellular Communicator Allows you to connect the XR150/XR550 Series to any compatible HSPA/SMS network.
Accessory Modules
270 Network Transient
Suppression Module
Provides transient surge protection for the ETHERNET Connector.
277 Trouble Sounder Provides local sounder for monitoring of panel operations and loss of Keypad Bus.
370/370RJ Lightning Suppressor Provides protection against voltage surges on panel input and output circuits.
893A Dual Phone Line Module Allows you to supervise two standard phone lines connected to an XR150/XR550 Series
panel. The 893A module monitors the main and backup phone lines for a sustained voltage
drop and alerts users when the phone line is bad.
Expansion Modules
710 Bus Splitter/Repeater Allows you to increase keypad or LX-Bus wiring distance to 2500 feet.
711 Single Point Zone Expanders Provides one Class B zone for connecting burglary devices.
714, 714-8, 714-16 Zone Expanders Provides Class B zones for connecting burglary and non-powered re devices.
712-8 Zone Expander Provides Class B zones for connecting burglary devices.
715, 715-8, 715-16 Zone Expanders Provides 12 Vdc Class B powered zones for connecting smoke detectors, glassbreak
detectors, and other 2- or 4-wire devices.
716 Output Expander Provides four Form C relays (SPDT) and four switched grounds (open collector) for use in a
variety of remote annunciation and control applications for use on the LX-Bus only.
717 Graphic Annunciator Module Provides 20 zone following annunciator outputs (open collector) for use in a variety of
remote annunciation and control applications for use on the LX-Bus only.
7
34, 734N, 734N-WIFI Wiegand
Interface Modules
Provides system codeless entry, and arming and disarming using access control readers.
Wi-Fi™ Module
763 Module Allows you to add Wi-Fi alarm signal communication to XR150 Series with Version 112 or
higher rmware and Level F hardware and XR550 Series panels with Version 112 or higher
rmware.
DMP Two-Way Wireless Devices
1100X/1100XH Receiver Supports up to 500/100 devices in residential or commercial wireless operation.
1100R Repeater Provides additional range for wireless devices.
1101 Universal Transmitter Provides both internal and external contacts that may be used at the same time to yield two
individual reporting zones from one wireless transmitter.
1102 Universal Transmitter Provides an external contact.
1103 Universal Transmitter Provides both internal and external contacts that may be used at the same time to yield two
individual reporting zones from one wireless transmitter. Requires EOL resistor for external
contact. Provides Disarm/Disable functionality.
1106 Universal Transmitter Provides both internal and external contacts that may be used at the same time to yield two
individual reporting zones from one wireless transmitter.
1107 Micro Window Transmitter Provides a wireless window transmitter.
1114 Four-Zone Expander Provides four wireless zones.
1116 Relay Output Provides one Form C relay.
1117 LED Annunciator Provides a visual system status indicator.
1118 Remote Indicator Light Provides a visual indication of a Panic situation.
1119 Door Sounder Provides a battery powered sounder.
1121 PIR Motion Detector Provides motion detection with pet immunity.
1126R Motion Detector Ceiling mount motion detector with panel programmable sensitivity and Disarm/Disable
functionality.
1127C/1127W PIR Motion Detector Wall mount motion detector with panel programmable sensitivity and Disarm/Disable
functionality.
1129 Glassbreak Detector Detects the shattering of framed glass mounted in an outside wall and provides full-pattern
coverage and false-alarm immunity.
1131 Recessed Contact Provides a recessed contact option for door or window applications.
1135/1135DB Wireless Siren Provides a wireless siren.
1137 Wireless LED Emergency Light Provides path lighting in the event of an alarm or trouble such as Burglary Alarm Output or
can be activated simultaneously by the panel via the Trip with Panel Bell feature.
1139 Bill Trap Provides a silent alarm option for retail and banking cash drawers.
1141 Wall Button* One button wall mounted wireless transmitter.
