DMP Electronics XR150 series User Manual

800-641-4282
INTRUSION • FIRE • ACCESS • NETWORKS
www.dmp.com 2500 North Partnership Boulevard
Designed, Engineered and
Manufactured in Springfield, Missour i
Springeld, Missouri 65803-8877
LT-1233 © 2017 Digital Monitoring Products, Inc.
17081
Certications
California State Fire Marshal (CSFM)
FCC Part 15
FCC Part 68 Registration ID CCKAL00BXR550
New York City (FDNY COA #6167)
XR550 with Encryption Only
NIST AES Algorithm Certicate #2350 128-bit
NIST AES Algorithm Certicate #2595 256-bit
SIA
Meets ANSI/SIA CP-01-2010 False Alarm Reduction
ANSI/UL 294 Access Control System Units
ANSI/UL 365 Police Sta. Connected Burg Alarm
Units & Systems
ANSI/UL 609 Local Burg Alarm Units & Systems
ANSI/UL 1023 Household Burglar
ANSI/UL 1076 Proprietary Burglar
ANSI/UL 1610 Central Station Burglar
ANSI/UL 1635 Digital Burglar
ANSI/UL 985 Household Fire Warning
ANSI/UL 864 Fire Protective Signaling 9th Edition
ANSI/UL 2017 General-Purpose Signaling Devices
and Systems
Compatible with Devices listed for
ANSI/UL 268 Smoke-Automatic Fire
Detectors
ANSI/UL 346 Waterow Indicators for Fire
Protective Signaling Systems
ANSI/UL 636 Holdup Alarm Units and
Systems Accessory
UL Bank, Safe, and Vault
UL Standard Line Security
UL Encrypted Standard Line Security
Export Control
The XR550 with encryption uses AES encryption and any
export beyond the United States must be in accordance
with Export Administration Regulations.
20.2 Connecting the 763
NOTE: POWER MUST BE REMOVED FROM THE PANEL PRIOR TO CONNECTING THE 763 TO THE XR150/XR550 Series
EXP HEADER. DAMAGE TO PANEL MAY OCCUR.
1. The included cable connects to the 763 6-pin header. See Figure 14.
2. Connect the opposite end of the cable to the panel EXP header provided on the XR150/XR550 Series panel.
20.3 Status LED
The 763 provides a Green link LED that displays constant to indicate network communication. See Figure 14 for LED
location.
20.4 Mounting the 763
Install the 763 away from metal objects. DO NOT MOUNT THE 763 INSIDE OR ON A CONTROL PANEL METAL
ENCLOSURE.
Mounting the module on or near metal surfaces impairs performance. The enclosure for the module should be
mounted using the supplied screw in the mounting hole. Mount the enclosure in a secure, dry place to protect the
communicator from damage due to tampering or the elements. It is not necessary to remove the PCB when installing
the enclosure.
1. Remove the cover.
2. Connect the included cable to the 763 6-pin header.
3. Hold the transmitter base in its mounting location.
4. Place the supplied screw into the mounting hole location to secure the housing to the surface.
INSTALLATION

DMP Electronics XR150 series Specifications

General

Brand	DMP Electronics
Model	XR150 series
Category	Control Panel
Language	English
