50 XT30/XT50 User Guide Appendix A
Arming and Disarming Event Displays
This displays any system areas arming or disarming.
Description
ARM 5:10P 10/17
WAREHOUSE
The warehouse area was armed at
5:10 PM. Press any select key or
area to display the area number and
user number.
Arming Event Types - There are two event types you may see here:
ARM - User armed the system DIS - User disarmed the system
User Check-In Event Displays
This shows when a user selected the email Check-in feature from
the User Menu. See page 16 for more information.
Description
MSG 3: 31P 10/17
CHECKIN USER: 16
User 16 selected the Check-in
feature at 3:31 PM on Oct. 17.
User Code Change Event Displays
This displays any user code additions, deletions, or changes.
Description
ADD 11:41A 10/17
US:19 BY US:12
At 11:41 AM user 12 added user 19.
User Code Event Types - There are three event types you may see here:
ADD - User added DEL - User deleted
CHG - User code or authority level was changed.
Zone Event Displays
This section displays alarms, troubles, and other events that could
occur on your protection zones.
Description
ALR 10:23P 10/17
BASEMENT DOOR
An alarm occurred at 10:23 PM on
October 17. Press any select key or
area to see the zone number and
zone type.
Zone Type - There are seven possible zone types you may see here.
FIRE - Fire PANC - Panic BURG - Burglary
EMRG - Emergency SUPV - Supervisory
AUX1 - Auxiliary 1 AUX2 - Auxiliary 2
Event Types - There are seven event types you may see here:
ALR - Alarm TBL - Trouble RST - Restore
FLT - Zone Fault SVC - Service Smoke Detector
LOW - Low battery MIS - Missing wireless transmitter
Note: LOW and MIS are for wireless systems only.
