Case 1: Machine adjustment during PP strap and PET strap conversion:
Method: Replace the cutter spring(Q-0080) on the cutter
Steps:
a. First loosen the screw(Q-T509 M4×20) on the side shield (Q-3007). Remove the left side
shield cover;
b. Loosen the screw on the cutter (Q-0078) with an Allen key, and take off the cutter;
c. Replace the pressure cutter spring(Q-0080) on the cutter: replace the pressure cutter spring
suitable for PP strap with the pressure spring suitable for PET strap. Put the cutter spring into
the corresponding hole, and then install the cutter back. After installing the cutter, tighten the
fixing screw on the cutter.
d. Then install back the side shield (Q-3007) and tighten the screws.
e. The method of replacing the PET strap cutter spring is the same as that of replacing the PP
strap cutter spring.
Note: PP strap cutter spring: long with slightly elastic force; PET strap cutter spring: short with
stronger elastic force(replacement cutter spring is included in the Kit for free).
Case 2: Machine adjustment for different strap width conversion:
Method: Replace the limit block
Steps:
a. Strap width switch from 14-16mm to 10-13mm: Install Q-0042(13mm left front strap guide
block) and Q-0053(13mm right front strap guide block), and then replace Q-0043(16mm
back strap guide block) with Q-0041(13mm back strap guide block);
b. Strap width switch from 10-13mm to 14-16mm: Remove the two parts Q-0042(13mm left
front strap guide block) and Q-0053(13mm right front strap guide block), and replace Q-
0041(13mm back strap guide block) with Q-0043(16mm back strap guide block).
5.3.3 Reference for Tension Force (Unit: N)
Gear Normal mode (H) Flexible mode (L)
