DMS Q31 - REPLACEMENT OF WEARING PARTS

Operation completed,
but failed to remove the
tool
The tension wheel cannot be
lifted up
Check if it is stuck by residual strap
Strap retraction function
failure
Check if the strap retraction switch
is faulty
Uneasily strap cutting
The cutter worn or the cutter
spring losing its elasticity
Replace the cutter or the cutter
spring
8. REPLANCEMENT OF WEARING PARTS
Note: please remove the battery before repairing the machine each time.
Wearing
Parts Name
Drawing No. Replacement Procedure
Cutter Q-0078
First remove the left shield screw, moving it away, then remove
the screw on the cutter and move it away, take out the cutter
and keep the cutter spring properly. Replace the cutter, install it
in the reverse order.
Welding
Tooth Plate
Q-A001
Remove the lower welding toothed plate by removing the
fixing screw of the lower welding toothed plate; replace the
toothed plate, then install it in the reverse order.
The Lower
Tighten
Toothed
P
late
Q-2040
Remove the screw fixing the toothed plate on the base, lift the
rocker lever, take out the toothed plate for replacement, and
then install it in the reverse order.
Tension
Wheel
Q-0010
First remove the left shield screw, moving it away, take out the
tension wheel, and then take out the two bearings in the tension
wheel; replace the tension wheel, and then install it in the
rev
erse order.
