9. SPARE PARTS LIST
Q31 Spare Parts List
No. Item No. Drawing No.
English Description Ratio
1 1030102202 A72 Screw M5x16 1
2 2010013130 Q-A001 Welding lower teeth plate 1
3 2010013147 Q-A002 Welding lower teeth plate fixing screw 1
4 1030102658 Q-A003 Split ring Φ4 4
5 2010013675 Q-A004 Pulley gasket 1
6 2010020285 Q-A005 Sliding gear block baffle 1 1
7 1030130815 Q-A006 Self tapping screw M2.5x6 10
8 1030119859 Q-A007 Nut M4 1
9 2011000203 Q-0004 Base rocker pin 1
