Corner Solutions
Corner Solutions without internal
Cantilever Platforms
Acornercanbecreatedinmanydi󰀨erentways.
Pleaseseethebelowexamplesforthemostcommon
solutions,whendealingwithaninternalorexternal
corner it is imperative that a 3 part side protection is
inplaceatalltimes.Itisalsoimportantthatsca󰀨olds
aretiedtotheadjacentstructureandhavesu󰀩cient
bracing.
This is the most basic layout for a corner. All Ledgers
are present at the deck level and an internal Standard
is used at the corner. A square bay is erected for the
cornerwhichcanbeeitherinternalorexternal.
The outside Ledger at platform level has been re-
placed with a Console Bracket. In order to create the
Guardrail a Standard is attached to the ternminal on
the Console Bracket. This minimizes the number of
components in comparison to the layout above.
Aybyreturniscreatedbyjoiningthesca󰀨oldsto-
gether anywhere along the span of the adjacent bay.
By using a Truss Ledger at the Plank level the Planks
can lock into the Truss Ledger at any point.
Bracing and Edge Protection removed for clarity.
