Page 22
10-01 Removing the driving mechanism
Remove the motor hood and tubular han-
dle as described in introduction.
10-01 Removing the driving mechanism
Remove the connecting muff as described
in 06-02.
10-01 Removing the driving mechanism
Only remove ignition and flywheel if cylin-
der is to be replaced.
➪
➪
➪
10-01 Removing the driving mechanism
Loosen and unscrew the 4 cylinder screws.
➪
10-01 Removing the driving mechanism
Lift out motor unit upwards in direction of
arrow.
➪
10 Piston and cylinder
