Program/Manufac turer/IOConfigurations



AnalogInputs
 CWReturnTemp CWSupplyTemp
Enable On/Off On/Off
Channel B001 B002
Setting Normal/HighRes. Normal/HighRes.
InputType Select/(On/Off) Select/(On/Off)
On/Off 
Direction* Reverse/Direct Reverse/Direct
DelayTime* #s #s
Selecttype 
Minimum* #.# #.#
Maximum* #.# #.#
Offset #.# #.#
Value #.# #.#
PowerDelay #
s #s
RunDelay #s #s
Units Temp/Press/Other Temp/Press/Other
DigitalInputs
Switches Enable Channel Action Delay Status 
HighPressure On/Off # Open/Close ###s Open/Close
LowPressure On/Off # Open/Close ###s Open/Close
WaterFlow On/Off # Open/Close ###s Open/Close
LoadShedding On/Off # Open/Close ###s Open/Close
ElecHtFlow On/Off # Open/Close ###s Open/Close
HandCool
 On/Off # Open/Close ###s Open/Close
HandHeat On/Off  #  Open/Close ###s Open/Close
RelayOutput
 Enable Channel Direction Status
SWPump Yes/No # NO/NC On/Off
CWPump Yes/No # NO/NC On/Off
Fault Yes/No # NO/NC On/Off
Compressor Yes/No # NO/NC On/Off
ReversingValve Yes/No # NO/NC On/Off
ElectricHeat* Yes/No # NO/NC On/Off
I/OConfiguration
AnalogInputs
DigitalInputs
RelayOutputs
