# Name Type Description
9 PRINT_LED_DP Output Output to activate green beacon light.
Active low, open drain output.
47 K Ohm internal pull-up resistor to +24
V.
10 SP_INPUT Input Spare input.
Active low with 47 K Ohm internal pull-up
resistor to +24 V.
To use this input, connect Ground from
the input signal to Ground on the
printer's IO socket.
11 485A RS485
Communication
RS485A, non-inverting driver output/
receiver input.
12 24V_FUSE Output 24 V DC electrical power output.
Protected by a 3 A fuse.
Maximum current output: 1.5 A.
This output is combined/shared with #5.
13 GROUND -
14 SP_SIG_DP Output Spare output.
Active low, open drain output.
47 K Ohm internal pull-up resistor to +24
V.
15 ALARM_LED_DP Output Output to activate green beacon light.
Active low, open drain output.
47 K Ohm internal pull-up resistor to +24
V.
SYSTEM DESCRIPTION
EPT077343 EN - Issue 1 - 11 November 2022 27
