ANTI SHOCK (OPTIONAL) INSTALLATION
Pinch Point. Risk of Injury.
Keep hands/fingers out of the anti shock clamp.
Hands and fingers may become caught in the anti shock clamp. If the
anti shock clamp closes on hands and fingers, injury may occur.
Required tools: 3 mm hex key
To install the optional print head anti shock clamp:
1. Install the screw labeled (1) in the image below.1.
2. Compress the clamp and install the screw labeled (2) in the image below.2.
INSTALLATION
EPT077343 EN - Issue 1 - 11 November 2022 47
