Item Name Description

Properties View and edit the properties of the selected object.

Undo Undo the last action.

Redo Redo the last action.

Zoom In Zoom into the label template.

Zoom Out Zoom out of the label template.

Zoom Reset Reset the zoom.

SYSTEM DESCRIPTION

EPT077343 EN - Issue 1 - 11 November 2022 37
