51
¡¡
‹
Oil pump assembly(9)
Full up the oil pump with engine oil and install the
pump to the cylinder body.
¡¡
‹
Oil pump mounting bolts
¡¡
‹
Oil cooler(11)
Tighten the cooler bolts to the specified torque. Start
from the middle and work out to either side.
¡¡
‹
Injection pump assembly (12)
Check the punched line of the injection pump body is
aligned to the pump bracket line.
Oil pump
Oil
"
ƒU" ; Injection pump fixing bolts
Arrow mark
Notched line
Notched line
Torque (kgƒUm)
3.8
(27.5 lb¡⁄ft)
Torque (kgƒUm)
2.6
(18.8 lb¡⁄ft)
