OP000510
7-1
Specification
OP000510
7Specification
GENERAL SPECIFICATIONS
DL200
ITEM SPECIFICATION
Standard Bucket Capacity (BOT / BOC)
1.9 m
3
(2.5 yd
3
) / 2.0 m
3
(2.62 yd
3
)
Vehicle Weight (STD / OPT) 11,300 kg (24,912 lb) / 11,645 kg (25,673 lb)
Engine (SAE J1995 Gross)
Emission U.S EPA Tier3 (EU Stage IIIA)
Maker and Model DOOSAN DL06
Type Turbo Charged, Air to Air Intercooled Direct Injection
Injection System Common-rail Controlled by Electronic ECM
Max. Horse Power 160 ps (118 kw) / 1800 rpm
Rated Horse Power 145 ps (107 kw) / 2100 rpm
Max. Torque 70 kg•m (686 N.m) / 1400 rpm
Transmission
Full Automatic Power -Shift Full Automatic Power Shift
Speeds 4 Forward, 3 Reverse
Brake Systems
Service Brakes Full Hydraulic, Separate Dual Line Wet Discs
Parking Brake Spring Applied / Oil Released on Front Axle, Wet Disc
Performance
Travel Speed 6.6 (4.1) /12.1 (7.5) / 22.6 (14) / 35 (21.7) km/h (MPH)
Steering Angle ±40°
Min. Tire Turning Radius *
(Out Tire Edge)
5,210 mm (17' 1")
Safe Operating Load 3,420 kg (7,540 lb)
Max. Breakout Force 10,500 kg (23,149 lb)
Boom Rise Time 5.8 ±0.5Sec.
Bucket Dump Time 1.1 ±0.4 Sec.
Boom Down Time 4.1 ±0.4 Sec.
Maximum Gradeability 30° (58%)
