OP000507Operating Controls
2-6
OPERATOR'S AREA
Figure 3, identifies controls in operator's cabin.
1
3
4
FG006189
2
Figure 3
Reference
Number
Description
1
Steering Console and Pedal
(See page 2-7)
2
Various Cabin Locations
(See page 2-42)
3
Right Side Switch Panel
(See page 2-27)
4
Seat Adjustment
(See page 2-53)
