DV11
Operation and Maintenance
7
Safety regulations & specifications
Printed in Mar. 2005 PS-MMA0608-E1A
Engine model
Items
DV11
Type
Wax pallet type (79 ∼ 94 °C)
Open at (°C) 83 °C
Open wide at (°C) 95 °C
Thermostat
Valve lift (mm) 8
Water temperature indicator Water temperature sensor mounted
Type Water cooled
Capacity (cc/rev) 550 (275 × 2 each)
Air compressor
Revolution ratio 1 : 1.265 (Engine speed : Air compressor speed)
Type Gear driven, vane type
Capacity (l/min) 16 / 18 / 25
Adjusting pressure
(kg/cm
2
)
125 / 150
Power steering
pump
Revolution ratio 1 : 1.265 (engine speed : pump speed)
Turbo charger Exhaust gas driven type (waste gate)
Engine stop system Fuel feeding shut-off by ECU
Engine brake Control by ECU
Alternator (voltage – capacity) (V - A) 24 - 60 or 24 – 150
Starting motor(voltage – output) (V-kW) 24 – 6.0
Air heater capacity (V – A) 24V – 2.64 kW
Battery capacity (V - AH) 20 - 150
