Doosan DV11 - Engine Sectional View (Cross)

DV11
Operation and Maintenance
15
Safety regulations & specifications
Printed in Mar. 2005 PS-MMA0608-E1A
1.5.2. Engine sectional view (cross)
1 Starting motor 8 Injector
2 Oil cooler 9 Oil spray nozzle
3 Cylinder block 10 Connecting rod
4 Cylinder head 11 Electric control unit (E.C.U)
5 Engine brake 12 Oil drain plug
6 Fuel high pressure pump 13 Oil suction pipe
7 Common rail
1
2
3
4
5
6 7
8
9
10
11
12 13
