z Refer to the chapter of 3.4 about
relation of the common rail system
and the electric control unit.
3.3.26. Crankshaft speed sensor
z Measure the clearance of the
assembling part of the sensor and
fly wheel, then assemble it with the
adjust shim.
Clearance
1. 0 ±0.1mm
Torque 1.0 kg.m
3.3.27. Camshaft speed sensor
z Measure the clearance of the
assembling part of the sensor and
timing gear, then assemble it with
the adjust shim.
Clearance
1. 0 ±0.1mm
Tor que 1.0 kg.m
3.3.28. Oil cooler
z Attach a gasket on the surface in
the oil cooler housing where the oil
cooler is installed.
z Tighten the oil cooler with fixing
bolts.
z Install the oil cooler assembly by
tightening the fixing bolts in the
zigzag order.
Electric control unit
Rubber cushion
Bracket
Crankshaft speed sensor
Adjust shim
Camshaft
speed sensor
