DV11
Operation and Maintenance
136
Common Rail Fuel-injection System
Printed in Mar. 2005 PS-MMA0608-E1A
Signal
Pin no.
BOSCH DOOSAN
Part name
2.36 I_A_CTS I_A_PAS02 Coolant temperature sensor signal
3.03 O_P_SVH13 O_P_SVH13 #3 cylinder injector power supply
3.04 O_P_SVH12 O_P_SVH12 #2 cylinder injector power supply
3.05 O_P_SVH23 O_P_SVH23 #6 cylinder injector power supply
3.06 O_P_SV13 O_P_SV13 #3 cylinder injector power return
3.07 nc G_R_GND01
3.08 nc G_R_GND02
3.09 O_P_SVH11 O_P_SVH11 #1 cylinder injector power supply
3.10 O_P_SVH22 O_P_SVH22 #5 cylinder injector power supply
3.11 O_P_SVH21 O_P_SVH21 #4 cylinder injector power supply
3.12 O_P_SV12 O_P_SV12 #2 cylinder injector power return
3.13 O_P_SV11 O_P_SV11 #1 cylinder injector power return
3.14 O_P_SV23 O_P_SV23 #6 cylinder injector power return
3.15 O_P_SV22 O_P_SV22 #5 cylinder injector power return
3.16 O_P_SV21 O_P_SV21 #4 cylinder injector power return
nc = not connected
