DV11
Operation and Maintenance
173
Commissioning and Operation
Printed in Mar. 2005 PS-MMA0608-E1A
z Allow on interval of 3-4 minutes
until the oil in the housing ② is
drained automatically. (is drained
automatically thorough the engine
by-passes to the oil pan)
z After remove the housing ②, wash
it cleanly, and remove the used
filter element by catching the
handle loop.
z Assemble the filter element after replace the new one. (The genuine filter
element should be used.)
z Insert the O-ring to the ho⑤ using. (The filter element and O-ring and sealing
are supplied simultaneously when the service components.)
z Assemble the oil filter housing to the oil filter head② .
z Assemble the oil filter element a’ssy after insert the sealing to the fixing bolts ⑥
.①④
Caution:
Do not forget to assemble the drain plug after the engine oil is drained.
Caution:
DAEWOO genuine part should be used when the oil filter element is replaced
