SP002030
Page 79
Electrical System
2. Turn marked knobs (1, Figure 72) at the rear side of the
cabin to open the cover.
3. Remove the filter attached to the cover and clean the
contaminated filter using compressed air.
4. Close the cover, replace the knobs, and secure the cover
to the support with butterfly bolts.
FG000441
1
Figure 72
FG000342
Figure 73
To Next Page
