DORMA CS 80 MAGNEO
10
8
7
6
5
4
3
2
1
ON
DIP switch
LED
light indicator
Potentiometer
hold-open time
Connection terminals for
external accessories
Mains switch
Energy mode switch
(Full-Energy/Low-Energy)
(located below the seal)
Potentiometer
speed
Reset button
Start
learning cycle
Actuated opening direction
4. System overview
Control unit and connection terminals for external accessories
Power supply
CS 80 MAGNEO
Control unit and connection
terminals for external accessories
