DORMA CS 80 MAGNEO
22
C
L
A = at leas t L + 120 mm
min. 50 mm
min. 70 mm
Closed position
Side with
connections
6mm
Bottom edge of lintel
X
mind. 70 mm
==
L/4
With
With glass clamping rail:
= Door panel height + 111 mm
= Door panel height + 71 mm
wooden door panel:
X
Dimension X has to be measured
at the highest point of the floor
within the movement range of
the door system.
= Door panel height + 75 mm
With DORMA MANET
single-point fixings
X
X
L
1750 2000 2250
A
C
mind. 1870
575
mind. 2120
700
mind. 2370
825
L/4
437.5 500 562.5
The wall must not be closed before the
system has been installed.
The connections should always be on
the side where the door panel is when
the door is in closed position.
Dimension stands for the operator
length.
Dimension indicates the distance
from the centre of the passage area to
the side of the operator where the
connections are located.
The distance between the door panel
and the floor should amount to 6 mm
and must not exceed 8 mm.
·
·
·
·
L
L/4
The holes for the cables must be
sufficiently big and must not have sharp
edges.
Please have a look at the table and the
drawing for the dimensions regarding your
operator.
7. Installation instructions for in-wall mounting
