Dorma CS 80 MAGNEO Technical Documentation

DORMA CS 80 MAGNEO
30
8
7
6
5
4
3
2
1
ON
8
7
6
5
4
3
2
1
ON
DIP switch
10. Connection of closing edge protection
This work may only be performed by properly qualified staff.
When a sensor is connected to the main closing edge
When a sensor is connected to the secondary closing edge
When sensors are connected to the main and secondary closing edge
When testable sensors for the protection of the closing edges are connected, the control unit
has to be adjusted to the sensors via the DIP switches.
Set DIP switch 1 to ON and DIP switch 3 to OFF.
Set DIP switch 2 to ON and DIP switch 3 to OFF.
3ON
OFF
OFF
OFF
= test high active
= test low active
sensor test for secondary closing edge activated
sensor test for secondary closing edge deactivated
sensor test for main closing edge activated
= sensor test for main closing edge deactivated
2ON
1ON
=
=
=
