Basic requirements
CS 80 MAGNEO
General information
CS 80 MAGNEO
Learning cycle
·
·
·
·
·
The is completely
mounted.
You can move the door smoothly over
the complete movement range.
When you connect the system to the power
supply (plug it in) the green light indicator
blinks and the operator has no function. You
can access the door manually.
In order to make the operator ready for
operation, you have to perform a learning
cycle.
The green LED goes on following the learning
cycle. The is now ready for
operation and operates in Low-Energy-Mode.
This "approach" describes the commissioning
of the standard door system. Accessories and
different operation modes can be adjusted
after the system has been commissioned.
Sensors are connected and adjusted
following the successful commissioning of
the system.
The light indicator (LED) will give you visual
feedback.
The settings stored during the commissioning
of the system can be overwritten by
performing a new commissioning.
In order to start the learning cycle:
The door must be open.
The operator must be switched on.
The movement range of the door must
be free of obstacles.
The green LED will blink before the first
learning cycle.
Apart from during commissioning, a
learning cycle has to be performed every
time the position of an end stop has
been adjusted or the weight of the door
has changed.
Press and hold the "Reset" button for more
than 3 seconds.
Do not interrupt the learning cycle as
the system currently learns all values it
requires.
During the learning cycle the door will:
The CS 80 MAGNEO is now ready for
operation.
How to switch the system from Low-Energy-
to Full-Energy-Mode
Only authorized staff (authorization on
the part of DORMA required) may
switch the CS 80 MAGNEO to Full-
Energy-Mode. As there are higher forces
in Full-Energy-Mode, the closing edges
have to be protected by safety sensors.
Speed adjustment
Adjustment of hold-open time
Open twice and close again. The LED will
blink green at certain intervals then it will
show a permanent green light.
Therefore we do not explain how to switch
the system to Full-Energy-Mode in these
instructions.
The maximum speed depends on
the weight of the door panel. You
can reduce the speed with the aid
of the potentiometer (infinitely
variable).
The door will close automatically
on expiry of the adjusted hold-
open time following it has
reached "open" position. You can
adjust the hold-open time
infinitely from 5 to 30 seconds
with the aid of the potentiometer.
Only use the enclosed red screwdriver
to perform potentiometer adjustments!
11. Commissioning
31
