ED700
Low Energy
Automatic Swing Door
DORMA
5
DORMA AUTOMATICS, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211
Lake Bluff, IL 60044 Fax: 877-423-7999
DL3038-010 Rev. B 6/08
E-mail: automatics@dorma-usa.com Subject to change without notice
Slide Track Arm (Pull)
0’- 6” Reveals
1. DC0847-01A ARM, UNIVERSAL SCISSOR CL
DC0847-01B ARM, UNIVERSAL SCISSOR DB
DK2494-01A KIT, DOUBLE EGRESS SISSOR ARM
EXTENDED SPINDLE REQUIRED FOR DOUBLE EGEESS APPLICATIONS
2. DS2516-01A ASSY, TRACK ARM RH CL
DS2516-01B ASSY, TRACK ARM RH DB
DS2219-01A ASSY, TRACK ARM LH CL
DS2219-01B ASSY, TRACK ARM LH DB
3. DS2409-01A ASSY, SLIDE TRACK
DS2409-01B ASSY, SLIDE TRACK
2
1
Scissor Arm (Push)
