Dormakaba EML 310 - Secure Mounting Bracket and Mag Lock to Shim (for 6 Headers Only)

dormakaba Header Installation Instructions with EML310/320 and 371/372
For use with DRS Rails and Patching Fittings (4-1/8”, 4-1/2”, 6” Headers)
933903
07-2019EML Header Shim
13
Secure mounting bracket
. Secure mounting bracket and mag lock to shim
(for 6” headers only)
Fig. 
.. Secure mounting bracket to shim
(pre-installed inside header tube) with
appropriate fasteners.
Hex key size
mm
.. Secure mag lock body to mounting bracket.
• Insert mag lock body screws into slots in mounting bracket.
Mounting
bracket
Mounting
bracket
Shim
Mag lock
body
.. Slide mag lock body
backward and into
place in slots.
.. Rethread captive
mounting screws.
.. Reinsert one ()
anti-tamper screw.
NOTE: Other anti-tamper
screw to reinsert later. Access
needed to wiring cavity.
Slots in
mounting
bracket
Mag lock
body screws
Captive mounting
screws
Anti-tamper
screw
Header
tube
Shim
Header
tube
Mag lock
body
Wiring
cavity
