Dormakaba EML 310 - Wiring Mag Lock Body; (For EML310;320) - Continued

dormakaba Header Installation Instructions with EML310/320 and 371/372
For use with DRS Rails and Patching Fittings (4-1/8”, 4-1/2”, 6” Headers)
933903 07-2019EML Header Shim
18
Wiring EML
Fig. 
.. Connect wire to terminal blocks shown in
Figure above.
.. If using [optional] Bond Alert (BA) and/or
standard Door Position Switch (DP): wire at
this time as well. See Figure above.
.. Delayed Relock Feature:
• Used to momentarily release lock and keep it
unlocked for a time period from  to 
seconds.
• IF REQUIRED - Wire a Normally Open
Momentary switch, such as Dorma , to the
two blue wires from J on the circuit board.
• IF NOT REQUIRED - The two blue wires must
be unplugged from the circuit board at J to
prevent possible lock malfunction.
.. Delayed Relock Time Delay Adjustment:
• Turn potentiometer (RW) CLOCKWISE to
increase delay time. (same for single or double
doors)
• Factory setting is zero seconds.
• If potentiometer (RW) is not set at zero
seconds, lock will enter delayed relock mode
each time power is applied, even if J has been
removed.
NORMALLY OPEN
NORMALLY CLOSED
COMMON
COMMON GROUND
/VDC INPUT
Optional BA
Sensor SPDT
Output contacts
rated for max .
Amp at  VDC.
Lock powered from
a Listed filtered
and regulated DC
Power Supply
RED: NORMALLY
CLOSED
BLACK: COMMON
GREEN:
NORMALLY OPEN
See Optional
Delayed Relock
Options Below
DELAY
RW
MAG
J
LED 
DELAY RELOCK ADJUSTMENT:
Turn clockwise to increase delay on EML310 single and
both sides of EML320 double door model.
Optional Delayed Relock Options - for use in a delayed-egress locking system, relock must be set to 0 seconds.
RED STRIPED: NORMALLY
CLOSED
BLACK STRIPED: COMMON
GREEN STRIPED:
NORMALLY OPEN
Single lock to release using
the delayed relock feature.
Two EML310 Locks to release together
using the delayed relock feature.
Both sides of an EML320 Lock to release
together using delayed relock feature.
J2 J2
J2 J2
Left circuit
board
Right circuit
board
N/O
Momentary
Switch
N/O
Momentary
Switch
Blue Wires
Blue Wires
Blue Wires
N/O
Momentary
Switch
J2
. Wiring mag lock body (for EML/) - continued
Standard DP reed switch contacts rated at
0.20 Amp @ 12VDC and 0.12 Amp @ 24VDC.
