Issued July 2024
Body Controller Softw are
Copyright 2024, The Heil Co.
Printed in the U.S.A.
Body Controller Software
123
Select Truck Type
Allow Program Setup, Chooses Body Type
N/A
J1939 Baud Rate
Changes controller J1939 Baud Rate 250k/500k
N/A
Section 4: I/O Functions
The following sheets details Input, and Output functions provided through the CORTEX Controller.
Note: Status of all the Inputs/Outputs can be monitored using the Insight In-Cab display. Refer section 5.05 for more details about
Diagnostic display options and INSIGHT display.
4.01: Standard Input Functions
A01 Grabber Open Push Button (Input %IX0.01)
This circuit monitors the ON/OFF status of the Grabber Open button. When this button is pressed, the Grabber Open input will be
ON.
Function Logic:
Input Device
Status
I/O Address
Status
Grabber Open Button
Activated
%IX0.01
ON
A02 Side Door Closed Proximity Switch (Input %IX0.02)
This circuit monitors the ON/OFF status of the Side Door proximity switch. The Side door should always be in the Closed position
(ON). If the Side door is open, the Hydraulic pump and Packer will be turned OFF. The Side door is opened only for Servicing/
Maintenance purpose.
Function Logic:
Input Device
Status
I/O Address
Status
Side Door Closed Proximity Switch
Activated
%IX0.02
ON
A03 Tailgate Closed Proximity Switch (Input %IX0.03)
This circuit monitors the ON/OFF status of the Tailgate Closed proximity switch. The input is ON when the Tailgate is closed.
Packer cylinder (Auto/Manual mode) is activated based on the status of this input.
Function Logic:
Input Device
Status
I/O Address
Status
Tailgate Closed Proximity Switch
Activated
%IX0.03
ON
A04 Packer Full Extend Proximity Switch (Input %IX0.04)
This circuit monitors the ON/OFF status of the Packer Extend Proximity Switch. The input is ON when the Packer is Fully Extended
which occurs during the Packer Extending operation or when ejecting the trash.
Function Logic:
Input Device
Status
I/O Address
Status
Packer Full Extend Proximity Switch
Activated
%IX0.04
ON
A05 Filter Pressure Switch (Input %IX0.05)
This circuit monitors the ON/OFF status of the Filter Pressure Switch. The input is OFF when the Filter is in Bypass.
