Function Logic:
Input Device
Status
I/O Address
Status
Filter Pressure Switch
Activated
%IX0.05
ON
A06 Packer Full Retract Proximity Switch (Input %IX0.07)
This circuit monitors the ON/OFF status of the Packer Retract Proximity Switch. This input is ON when the Packer has reached its
home position (i.e. fully retracted position). When the input is OFF it is considered that the Packer is not at home position (i.e. Packer is
either Extending or Retracting).
Function Logic:
Input Device
Status
I/O Address
Status
Packer Full Retract Proximity Switch
Activated
%IX0.07
ON
A07 Low Torque Pressure Switch (Input %IX0.12)
This circuit is only functional on a Python unit. It monitors the ON/OFF status of the Low Torque Pressure Switch. This pressure
switch monitors the pressure on hydraulic Pump1. The input is on when pressure reaches the pressure switch setpoint.
