Function Logic:
Input Device
Status
I/O Address
Status
Low Torque Pressure
Switch
Activated
%IX2.05
ON
A08 Packer Extend Push Button (Input %IX0.14)
This circuit monitors the ON/OFF status of the Packer Extend button. When this button is pressed, the Packer Extend input is
ON.
Function Logic:
Input Device
Status
I/O Address
Status
Packer Extend Button
Activated
%IX0.14
ON
A09 System Power Switch (Input %IX0.15)
This circuit monitors the ON/OFF status of the System Power Switch (“mushroom button”). This “mushroom button” should be in
“Up” position for the system to be operative. If “Depressed” system power will be turned OFF.
Function Logic:
Input Device
Status
I/O Address
Status
System Power Switch
Activated
%IX0.15
ON
A10 Chassis Neutral Signal (Input %IX1.04)
This circuit monitors the Transmission Neutral circuit. This input is enabled when the Engine transmission is put into Neutral.
Function Logic:
Input Device
Status
I/O Address
Status
Chassis Transmission
In Neutral
%IX1.04
ON
A11 Hydraulic Pump Enable Push Button (Input %IX1.05)
This circuit monitors the ON/OFF status of the Hydraulic Pump Enable button. This is a momentary toggle switch which when
turned ON will enable the Hydraulic Pump Input.
Function Logic:
Input Device
Status
I/O Address
Status
Hydraulic Pump Enable Button
Activated
%IX1.05
ON
A12 Packer Retract Push Button (Input %IX1.06)
This circuit monitors the ON/OFF status of the Packer Retract button. When this button is pressed, the Packer Retract input is
ON.
Function Logic:
Input Device
Status
I/O Address
Status
Packer Retract Button
Activated
%IX1.06
ON
