Body Controller Software
126
A13 Grabber Full Open Proximity Switch (Input %IX2.00)
This circuit monitors the ON/OFF status of the Grabber Open proximity switch. This input is ON when the
Grabber is fully Open (i.e. Release the Can).
Function Logic:
Input Device
Status
I/O Address
Status
Grabber Full Open Proximity Switch
Activated
%IX2.00
ON
A14 Tailgate Control Proximity Switch (Input %IX2.02)
This circuit is only functional on a Multi-Pack unit. This circuit monitors the ON/OFF status of the Tailgate Control Proximity
Switch. This input is used along with the Remote Throttle Advance switch to speed and advance the engine idle. This is activated by
using the hydraulic control handles on the Tailgate.
Function Logic:
Input Device
Status
I/O Address
Status
Tailgate Control Proximity
Activated
%IX2.02
ON
A15 Grabber Close Pressure Switch (Input %IX2.03)
This circuit monitors the ON/OFF status of the Grabber Closed Pressure switch. This input is ON when the pressure in the Grabber
cylinder reaches the set point.
Function Logic:
Input Device
Status
I/O Address
Status
Grabber Close Pressure Switch
Activated
%IX2.03
ON
A16 Chassis Service Brake (Input %IX2.04)
This circuit monitors the ON/OFF status of the Chassis Service Brake. This input will be ON when the Service brakes are applied.
Function Logic:
Input Device
Status
I/O Address
Status
Chassis Service Brake
Activated
%IX2.04
ON
A17 Packer Pressure Switch (Input %IX2.05)
This circuit monitors the ON/OFF status of the Packer Pressure Switch. The Packer Pressure Switch Time
is a programmed time delay which delays the response to the activation of this input. This input is used to turn ON/OFF the Packer.
This input is used to retract the packer automatically when the Body packs out.
Function Logic:
Input Device
Status
I/O Address
Status
Packer Pressure Switch
Activated
%IX2.05
ON
A18 Grabber Close Push Button (Input %IX2.06)
This circuit monitors the ON/OFF status of the Grabber Close button. When this button is pressed, the Grabber closed will be
turned ON.
Function Logic:
Input Device
Status
I/O Address
Status
Grabber Close Button
Activated
%IX2.06
ON
